Networking

A sandbox with no network config gets no NIC and zero egress. That is the out-of-the-box experience; everything below is how you open exactly as much as a workload needs. How the enforcement works under the hood lives in the network model.

crucible default-deny egress

A sandbox created with --net-allow pypi.org resolves and reaches pypi.org over HTTPS, while every other host is refused at the DNS proxy. The allowlist is the whole reachable surface.

Allow specific hostnames

The primary mode: enumerate the hosts the workload may reach. From the CLI:

crucible run --net-allow pypi.org --net-allow '*.pythonhosted.org' -- pip download requests

Over the API, the same policy is the network field of the create request:

POST /sandboxes
{
  "vcpus": 1,
  "memory_mib": 512,
  "network": {
    "enabled": true,
    "allowlist": ["pypi.org", "*.npmjs.org", "github.com", "objects.githubusercontent.com"]
  }
}
  • network absent means no network (equivalent to {"enabled": false}).
  • network.enabled = false means no NIC attached; other network fields are ignored.
  • network.enabled = true with an absent or empty allowlist is a 400. An explicit allowlist is required; unlisted "full internet" is not a supported shape of this mode.

The sandbox response echoes the applied policy along with the assigned addresses:

{
  "id": "sbx_...",
  "network": {
    "enabled": true,
    "allowlist": ["..."],
    "guest_ip": "10.20.0.14",
    "gateway": "10.20.0.13"
  }
}

Allowlist syntax

Two rules, case-insensitive:

  • Exact match: pypi.org.
  • Single-label wildcard: *.npmjs.org matches registry.npmjs.org and www.npmjs.org, but not a.b.npmjs.org or bare npmjs.org.

No regex, no ports. Entries are lowercased and trailing dots stripped (pypi.org. becomes pypi.org). A bare * is rejected at config time (that is "all internet" and must be requested explicitly via full egress), and wildcards are only valid in the first label (*.foo.*.com is rejected).

Widen egress for trusted workloads

For an app you deploy yourself, "enumerate every hostname" is often the wrong default. Two opt-ins widen egress without weakening the SSRF guard:

  • Full egress (full_egress in the API, --net-full-egress on the CLI): reach any public host. The DNS proxy answers any name and the firewall accepts all destinations except the always-blocked ranges below.
  • CIDR allowlist (allowlist_cidr in the API, --net-allow-cidr 203.0.113.0/24 on the CLI): reach IP literals in a public prefix directly, which the hostname allowlist cannot express.

What a denied request looks like

  • A blocked connection times out silently. There is no ICMP unreachable, so probing for reachable hosts yields no signal.
  • A denied DNS lookup returns NXDOMAIN rather than REFUSED, which is less clueful that a filter exists.
  • IP literals never work in allowlist mode. curl http://93.184.216.34 does no DNS lookup, so that address was never attested by the DNS proxy and the packet is dropped. Reaching literals is exactly what the CIDR mode is for.

Inbound isolation

Networking is egress-shaped, but port publish (-p) and the ingress proxy send traffic toward a guest. Both preserve isolation:

  • Inbound reaches a guest only from the daemon. The publish forwarder and the proxy dial the guest's IP from the daemon's own network namespace over the sandbox's veth. There is no DNAT and no listener inside the guest's netns that a third party can reach.
  • Peers cannot reach each other. Each sandbox has its own /30 in its own netns, and RFC1918 egress is always blocked, so one guest cannot reach a neighbor's guest IP, published port or not.
  • The proxy is not a lateral path. A guest cannot reach the proxy or publish listeners at all — the host input chain drops every guest-initiated packet to any host-local address (iifname vh-* drop, after the established/DNS accepts), even under full egress and even to the host's public IP. So one app can never reach another app's instance through the proxy, published or not; the only route to a guest is the daemon dialing in over its own veth.

IPv6 at the edge

Guests are IPv4-only, but the inbound edge is dual-stack. The proxy and publish listeners are plain TCP listeners in the daemon, so a wildcard bind accepts both families, and the daemon dials the guest over v4 — clients never see the family hop:

  • --proxy-listen :80 serves the proxy over IPv4 and IPv6.
  • -p 8080:80 publishes on all interfaces, both families.
  • -p '[::1]:8080:80' pins a published port to a specific IPv6 address (bracketed, as in docker); a specific v4 address stays v4-only — an explicit address is the operator's choice, not a hint to mirror it.

X-Forwarded-For carries the client's address in either family. Guest-side IPv6 (v6 guest addresses, v6 egress rules) remains deferred.

Packet capture (debug)

crucible sandbox capture <id> (or app capture <name>) streams a live packet capture of a guest's traffic as standard pcap — captured host-side on the sandbox's veth in the root netns, so it needs no in-guest tcpdump and works for distroless/scratch images.

crucible app capture web --filter 'tcp port 8080' -w web.pcap   # then open in Wireshark
crucible sandbox capture sbx_… --max-seconds 30 | wireshark -k -i -
  • Bounded always — --max-bytes (default 50 MiB) and --max-seconds (default 60 s) cap every capture; --snaplen sets per-packet bytes.
  • Filter is a BPF expression, validated (no shell/option injection) and passed to the host's tcpdump.
  • Gated + audited — payloads are sensitive, so it requires a token granted the default-deny capture scoped op (never implied by read), and the daemon logs every capture (token, instance, filter, caps). Needs tcpdump on the host.
